Sale

Manure Removal Belt System

$198.00 $148.00

Rated 0 out of 5
(be the first to review)

Manure removal belt machine is specially developed for layer chicken cage farms. The width of the manure cleaning belt can be customized with a thickness

Description

Manure Removal Belt System For Chicken Farm

►Manure removal belt system Advantages  :

Can directly transfer the chicken manure to the chicken house, reduce the smell of the chicken house, provide a clean and comfortable growing environment for the chicken, chicken to epidemic prevention effect to reduce the incidence of disease, while saving labor costs, time and effort to improve the efficiency of breeding.

►Application of manure removal belt system:

 Suitable for the layer chicken cage or stacked  chicken cage farming

►Structural features of manure removal belt system:

Conveyor type manure cleaning machine is mainly composed of motor deceleration equipment, chain drive, main and forced roller, fecal bearing belt, etc.
  • The bottom cage is provided with a manure cleaning belt of the same width as the whole row of cages, and adopts an efficient manure cleaning motor, which is stable and reliable in operation.
  • The glue hanging driving roller and the segmented glue hanging and pressing roller have less muck and no slip.
  • The manure cleaning belt rotates 360 ˚ in a complete circle, and the two ends of the manure belt support are slightly higher, so as to avoid the overflow of chicken manure from both sides of the manure belt and ensure the cleaning of the top of each layer of cage.

►Working principle of manure removal belt system:

Belt Conveyor manure remove plate installed at the bottom of the chicken cages, when the machine starts, by the motor, reducer after chain rolling automatic roll each work, under the extrusion of forced to roll and automatic roll friction, rolling bearing dung to cage length direction, the chicken manure to the end, dung plate shave is set by your end, then chicken manure cleaning end work.

►Product configuration parameters of manure removal belt system:

1)  Primary layout parameters: driving power 1 ~ 1.5kw, running belt speed 10 ~ 12m/min, conveyor belt width can be customized, operating length ≤100m.
2)  Manure removal belt machine is specially developed for layer chicken cage farms. The width of the manure cleaning belt can be customized with a thickness of 1.2mm. The raw material is PP or PVC board.Bottom chicken cage below equipped with a layer of conveyor belt, complete chicken manure finishing.
3)  The high-quality cycloid needle wheel reducer is selected for the conveyer belt manure cleaning machine to ensure the rationality of the output transmission ratio.The motor and reducer are directly connected with small volume and simple operation.
4)  The thickened scraper made of special materials ensures the extra long service life of the manure cleaning machine. The scraper is manufactured by high-precision CNC machine tools and never deforms.

Comparison of scraper and  manure removal belt

  • Traction manure cleaning machine is mainly designed for the chicken farm ladder type cage and broiler raised bed type vertical manure cleaning system, each for 2-4 rows of chicken cage or broiler bed type manure ditch, can also be made into a mobile head, the width of the scraper according to the size of customer designed manure ditch.The special thickened scraper ensures the long service life of the machine.The scraper is made by high-precision CNC machine tool and never deforms.Special transmission chain wear resistance, corrosion resistance, long life.
  • Conveyor type manure machine can be directly transferred to the chicken manure outside the chicken house, reduce the smell of the chicken house, provide a clean and comfortable growing environment for the chicken, chicken to epidemic prevention effect to reduce the incidence of disease, while saving labor costs, save time and effort to improve the efficiency of breeding, this is the magic power of conveyor belt manure machine.

Manure removal belt system

manure removal belt system
